XLR SIP Codec ‘Touch’

$499.00

As seen on forbes.com & Radio World.

Ships from:
USA
United Kingdom

Category:

Make and receive SIP calls for remote radio shows, media tours and podcast interviews, with this simple desktop touchscreen IP codec. Just connect to an audio mixer with mix-minus configured, or connect an XLR mic* and a pair of headphones.

The XLR SIP Codec from In:Quality connects to your existing internet connection and allows you to call to/from radio stations in full studio quality, thanks to its use of the Opus codec.  It can be shipped pre-configured with your own unique sip.audio address, and quick-dial buttons for your regular destinations.  It also functions as a phone hybrid and ISDN codec, without needing a physical phone or ISDN line.

Use the on-screen controls to adjust input and output levels, and to mute the mic for privacy, or to cough.  Includes on-screen digital clock.

* Note: The input may not be suitable for some dynamic or low-sensitivity microphones, or for high performance applications.

Included with this purchase:
XLR SIP Codec ‘Touch’
Power Adaptor
12 months sip.audio subscription (click here for renewal rates – bulk discount available)

An ethernet cable is required, to connect the device to your internet router.



FAQs

Which radio stations can I connect with?
Find SIP enabled radio stations on our SIP Studio Map. An easy way for radio stations to call SIP codecs is to dial the SIP address from the dial pad in ipDTL.  Any station with a Comrex IP codec or similar, can receive SIP calls, once the unit has been configured with a SIP account.
Can I dial ISDN and phone numbers from this device?
Yes, and you can create quick-dial buttons to dial with one touch of the screen. You’ll need to upgrade your sip.audio subscription to allow ISDN and phone calls.
Can I receive inbound ISDN and phone calls?
There is a way to receive an ISDN call via a pre-configured quick-dial button.  ISDN numbers are assigned dynamically on demand, or you can get your own LA area ISDN number with your sip.audio subscription.  A package including a Tel subscription is required for inbound ISDN and phone calls.
Can I control the device without using the touchscreen?
Yes.  You can access it through its IP address from a nearby computer.
Can I connect the XLR SIP Codec to the internet using wifi?
Wi-Fi or mobile broadband are the most common causes of radio interviews dropping off. To ensure reliability, our SIP Codecs connect to your broadband router using a physical cable.  Most wifi routers have ethernet sockets on the back.  You can use an extra long ethernet cable, or ‘Powerline’ adaptors where cable routing is not an option. If you still want to use wifi, please get in touch to discuss viability.

Warranty & Support

  • Free repair or replacement, while sip.audio subscription remains active, up to 5 years.
  • Free technical support via support.inqualitymedia.com.

Technical Specifications

Protocols SIP
EBU Tech 3326 / N/ACIP (partially compliant)
STUN
AES67 (beta)
Codecs Opus
G.711
Audio I/O 2 x XLR Balanced Output (L+R) – Line level
2 x XLR Balanced Input (L+R) – Switch between Line & Mic level (with or without 48v phantom power)*.
* May not be suitable for some dynamic or low sensitivity microphones.
1/4″ Headphone jack with optional low latency microphone monitoring.
USB Audio – Not available while XLR connectors are active.
AES67 (beta) via ethernet.
Network Ethernet (DHCP or Static)
Power AC 100-240v 0.5A 50-60Hz
DC 5.1v 3A USB C
USB 4 x ports
Support for audio, keyboard, mouse
1.2A max USB power (0.5A per port)

Product Manual

Delivery within USA or UK takes between 2 & 5 working days.  Other addresses can take a little longer.
